Wednesday, December 31, 2008

Super Speed Plane







J-10 Fighter





Wednesday, December 24, 2008

Tuesday, December 23, 2008

Futaba 10CHP FASST 2.4GHz Air TM-10 TX + R6014FS RX



10-Channel 2.4GHz Computer System


The 2.4GHz system that offers the impossible: Pro-level features at a sport-system price.
Some people feel that a 2.4GHz system with a built-in module will always offer better response than a modular system. Nothing could be further from the truth.
The 10C is a modular system, yet offers response superior to most “dedicated� systems. Why? Because response doesn’t depend on whether your module is built-in or modular. It depends on whether your signal starts in analog or digital form.
Converting a signal from analog to digital form requires processing time — what you experience as lag. The 10C, on the other hand, was designed with a totally digital data stream. The signal starts digital and stays digital. Since no additional processing is needed, there’s no lag, either — just virtually instantaneous, real-time response.
And because the 10C is modular, you can use the TM-10 module to fly 2.4GHz-equipped aircraft…or replace it with a 50 or 72MHz module, and fly existing models without added equipment or expense.

10C System Overview:
- Big, 160 x 72 LCD with backlighting, adjustable contrast & auto-off
- Dial ‘n Key™ programming w/joystick navigation
- 15-Model memory (expandable w/optional CamPACs)
- 10-character user name
- 10-character model name
- 2048 resolution in FASST 10-channel mode
- Basic & Advanced menus
- Enhanced airplane, heli & glider software
- Smart Switch Technology™ (SST) — Logic Switches allow you to activate a function when specified switch and/or
stick positions occur
- Up/down on/off timer (activate by stick or switch)
- Tracks service hours for radio and models
- Mode 1-4 selectable (Modes 3 & 4 programmable)
- Assignable functions/switches
- Auxiliary channel screen — for 1-step function/switch assignment & eliminating unused auxiliary functions
- 2 proportional slider switches
- Digital trims on all 4 main channels
- Trim memory & sub-trims (all channels)
- Adjustable trim steps (1-40)
- Fail-safe, servo reversing & EPA
“Full Functionality� trainer system (cord required)
- Flap switch (3-position)
- Retract switch
- Rotary Dial (3)
- Adjustable Throttle Cut/Idle Down
- Sticks w/length & tension adjustments
- Servo cycle w/bar graph displays
- Constant trim, voltage, name and timer display

10C Specifics:

Advanced Airplane Menu
- 8 Programmable Mixes (4 linear/ (4) w/5-point curves)
- 9 Factory-Defined Mixes: Elevator-Flap; Ailvator (for dual elevator servos); Throttle-Needle; Aileron Differential; Flaperon; V-Tail; Elevon; Snap Roll; and Air Brake w/elevator delay
- Dual/Triple rates (4 ch.)

- Exponential (4 ch.)

- Idle down
- Throttle cut
- Throttle delay
- Throttle Hold & Idle-up w/delay
Plus
- 2 independent gyro settings
- 7-point throttle curve
- Flap trim

Advanced Glider Menu
- 8 Programmable Mixes (4 linear/ (4) 5-point curves)
- 12 Factory-Defined Mixes: Butterfly-Elevator (2); Elevator-Flap; Chamber Mix (w/ail/ele/rdr adj.); Aileron-Flap; Aileron-Rudder; Flaperon; V-Tail; Flap Trim; Butterfly w/spoiler adj; and 4-point Offset (w/camber adj. for basic/launch/thermal/speed)
Plus
- Adjustable spoiler
- Adjustable Throttle Cut
- Single/Dual Aileron and Flap Servo Selections
- Start, Speed, Distance & Landing conditions, Adjustable Airbrake Activation
- Adjustable Motor Cut

Enhanced Features:
- (2) Slider Switches
- (3) Rotary Dials
- More Programmable Mixes
- More Factory-Defined Mixes
- R6014FS 14 Channel Receiver
- TM-10 2.4GHz Transmitter Module

Thursday, December 18, 2008

Monday, December 15, 2008

SSV-9764MG / High Torque Servo w/ Metal Gear Specification

RM150

Complete Specification check here

Item No:

SSV-9764MG (Ball Bearing+Metal Gear)

Weight:

48grams / 1.58oz.

Dimensions:

40.5 x 20 x 38.5 mm / 1.60 x 0.78 x 1.54 in.

Input Voltage

3.6V ~ 6.0V

Torque At 4.8V:

8.2kg/cm , 120oz/in

Torque At 6.0V:

9.7kg/cm , 132 oz/in

Speed At 4.8V:

0.14sec / 60 deg at no load

Speed At 6.0V:

0.12sec / 60 deg at no load

Sunday, December 14, 2008

RC PLANE PLANS




Laman web banyak plans rc plane
http://plans.aerofred.com/

Friday, December 12, 2008

Wilga 2000 rebuild after crash













rebuild :-
- vertical stablize
- horizontal stablize
- main wing
- cooling
- motor mounting
- brushless motor

Thursday, December 11, 2008

Real Scale Cabin



Owner : Syed Kecik

Titan E325



- remote kaler baru
- canopy pun kaler baru
- blade kayu jer

Wednesday, December 10, 2008

New HSP Brushless Setup


Brushless Motor Setup


-Brusless ESC 30A


-Brushless Motor 3700kv

Power Supply by FieR


X-Chager LiXX Balance
Price Rm : 250.00
-Inteligent Chager
-Nicd,Nimh,Lipo & Pb Battery
-Max Output 14v & 5A


Pb Sealed Lead Acid Battery
Price : Rm 55.00
-12v
-7.2 A


TELETRON DC Power supply
Price Rm : 50.00
-14v & 12v
-Max 6A

My Glider


Design terbaru my glider


Thursday, December 4, 2008

Wilga-2000























Introduce Product Basic parameter
Wingspan:1160mm
Fuselage total length:888mm
Wing loading:35g sq.dm
Main wing area:16.82sq.dm
Flying weight: landplane: 550g floatplane:600g
Color box dimension: 1053 X 318 X 129mm
Carton dimension: 1071 X 415 X 660mm(6 color box/ctn, G.W.:19.5kg)

Basic collocation
Landplane>>
Motor:290ED motor with decelerator.
ESC:15A Brush ESC
Propeller: 8 x 6 three-bladed propeller
Battery:9.6V 1000MAH NiMH battery
Charger: 10.8V charger
R/C system: PPM-FM 4 channel proportional R/C system
Floatplane>>
Motor:290ED motor with decelerator.
ESC:15A Brush ESC
Propeller: 8 x 6 three-bladed propeller
Battery:11.1V 1200MAH Li-polymer battery
Charger: 12.6V Li Charger
Undercarriage:pantoon
R/C system: PPM-FM 4 channel proportional R/C system
Upgraded collocation
landplane:SP2830-26 out-runner brushless motor,18A brushless ESC,11.1V 1200MAH Li-polymer battery.
floatplane:SP2830-26 out-runner brushless motor,18A brushless ESC.
Main Character
●Steady in flight and very easy to master
●Great at slow-speed for easy flying
●Great for restricted-space and low altitude flying .
●Excellent control and stability. It can perform the loops, rolls and inverted flight aerobatics.
●Elegant styling and design
●It can be converted to a floatplane with the same outstanding performance.
1. Wilga-2000 has been independently developed by Shenzhen Sapac Industry CO.Ltd.
The high wing is very suitable for beginners and mid level flyers.
2. It is a 4-channel proportional R/C airplane with full functions that provide great performance
at slow speeds and low altitudes It has a very light body which provides for safe flying.
3. Wilga-2000's neutral flight tendencies allow for quick recovery in even the most extreme
situations. All you need to do is cut the throttle, release the elevator and it will resume.
Pontoon details
Length: 600MM
Width: 600MM
Height: 65MM
Weight: 25g(each)
Efficient tonnage: 500ML(each)
Matching style: wingspan 800-1200 MM, flying weight around 1000g R/C 、petrol airplane.



The SAPAC pontoon meets the demands of float flyers in many ways. It has all the clean and
efficient lines of full size pontoons and has the ability to float and lift heavy planes into the air,
while adding very little weight to the aircraft. Because of its design, your aircraft will track
straight and cut smoothly through the water from initial throttle advance through the step
and into the air. Once in the air, you will experience great flying characteristics and performance.
And just like many advanced full size float planes your aircraft will take off and land not only from
the water, but from grass and snow too. We highly recommend SAPAC pontoons for the beginner
and experienced flyer.

RM180 (kit only)
RM350 (RTF)
